智能裁床技术参数资料Intelligent cutting technology parameter data
|
产品型号 product model |
JR-3220CC |
|
裁剪高度cutting height (Max Thickness) |
70mm |
|
有效裁剪宽度 effective cut width(Work Width) |
1900mm |
|
有效裁剪长度 effective cut length(Work Length) |
3200mm |
|
运刀方式carrier way |
往复式运刀Reciprocating carrier |
|
裁断速度cutting speed |
0-60m/min |
|
裁刀研磨Cutting knife grinding |
双轮对旋研磨摆动磨刀The double wheel grinds and grinds the knife |
|
吸附方式adsorption model |
抽真空方式，变频控制Vacuum mode, frequency conversion control |
|
裁切输送带Cutting conveyor belt |
尼龙刚毛砖Nylon bristle brick |
|
安全装置safety device |
自动感应auto-induction |
|
使用电源power supply |
三相AC380V/50Hz/25Kw |
|
操作电脑Computer operation |
Ordinary computer，Windows7 |
|
操作面板operation panel |
液晶触摸屏lcd touch-screen |
|
裁剪参数输入Cut parameter input |
LAN，USB |
|
装置重量installation weight |
3000Kg |
标准装备功能Standard equipment function
l 裁剪速度自动调整cutting speed automatic adjustment
l 裁剪真空二次补偿tailor vacuum secondary compensation
l 触摸屏 touch screen
l 打定位孔positioning hole
选装功能The optional features
l 智能刀具系统smart cutter system
l 刀具冷却cutter cooling
l 移动式裁剪装置movable cutting device
l 自动送料装置automatic feeding device
l 条码扫描barcode scanning
操作系统The operating system
l 支持排料图整体旋转、刀口转换support the whole discharging figure rotation transformation, incision
l 支持单片重裁support monolithic heavy cutting
l 支持一键删除重叠区域（支持去除重复线）support a key delete overlap (support to remove duplicate line)
l 裁剪系统操作简便，易于操作 cropping system operation is simple, easy to operate
|
LC 有效裁剪长度effective cut length |
WC 有效裁剪宽度effective cut width |
A1 |
A2 |
A |
B |
|
3200 |
1900 |
850 |
1500 |
7550 |
3200 |
